Molex Cube PCB Mount Antenna

This is a surface mount cube GPS antenna from Molex. It has a frequency range of 1.556GHz ~ 1.607GHz.

AUD$ 4.90

Special Order

Shipping from $2.90

+380 more from our supplier in 7-10 days

Our Code: SKU-011151

Supplier Link: [SparkFun MPN:29203]

Description

This is a surface mount cube GPS antenna from Molex. It has a frequency range of 1.556GHz ~ 1.607GHz.

Specifications

Frequency:
- Band #1: 1556MHz ~ 1566MHz
- Band #2: 1571MHz ~ 1580MHz
- Band #3: 1597MHz ~ 1607MHz
Electrical Connectivity: SMD
Peak Gain (dBi):
- 0.6 @ 1561MHz
- 1.1 @ 1575MHz
- 1.1 @ 1602MHz
Return Loss - S11 (dB): <-10
Total Efficiency:
- >55% @ 1561MHz
- >57% @ 1575MHz
- >60% @ 1602MHz
Polarization: Right Handed Circular
Radiation Pattern: Omnidirectional
