The Tamiya 75026 Mini Motor Set is a more powerful brushed DC motor for the Tamiya Mini Motor Gearboxes.


Description

Tamiya 75026 Mini Motor Set with included parts

Tamiya 75026 Mini Motor Set with included parts

This 030-size motor can replace the brushed DC motor included with the Tamiya Mini Motor 4-speed, 8-speed, and 12-speed gearboxes and has 20% more power than the motor included with those gearboxes.

The Tamiya 75026 Mini Motor set includes:

  • One motor
  • One 8 toothed 0.5M pinion gear
  • Vinyl tubing
  • Double sided tape

This motor is intended for operation around 3 V.


Specifications

Dimensions

Size: 19 x 16 x 12 mm1
Weight: 0.39 oz2

General specifications

Free-run speed @ 3V: 10500 rpm
Free-run current @ 3V: 100 mA
Stall current @ 3V: 1.1 A
Stall torque @ 3V: 0.3 oz·in

Notes:

1
Not including the shaft.
2
Without included hardware.
