IR Reflectance Sensor - QRE1113

The QRE1113 is a small IR reflectance sensor. This sensor is often used in line following robots because, if it can sense if a surface is white or black. There are four pins on the QRE1113 - two control the IR emitting LED while the other two are the collector and emitter of a phototransistor.

AUD$ 2.70

Special Order

We can ship 91 more in 7-10 days

Our Code: SKU-000451

Supplier Link: [SparkFun MPN:9542]


Description

The QRE1113 is a small IR reflectance sensor. This sensor is often used in line following robots because, if it can sense if a surface is white or black.

There are four pins on the QRE1113 - two control the IR emitting LED while the other two are the collector and emitter of a phototransistor. The IR diode has a max forward current of 50mA and operates at 940nm.

Breakout boards with analogue and digital outputs are also available.


Specifications

  • Phototransistor output
  • No contact surface sensing
  • Miniature package
  • SMT gull wing leads

Documents:
