Slip Ring - 12 Wire (2A) Gold fiber brush and rings

AUD $27.95

In Stock: Ships Today

Back orders: Ship 96 units in 7 days

Our Code: CCW-20149

Supplier: [SparkFun MPN:13065]

This capsule slip ring enables a complex electrical data or power connection to rotate continuously without getting in a bit knot.The internal connections are made with gold alloys to ensure smooth data transfer and power connections.Make your own radar station or something a little more low key.


Description

Internally the slip ring has gold alloy fibers contacting gold alloy rings to ensure that the transfer of power or data is done reliably. The device will allow continual rotation around 360º without tangling your wires. It works up to 250RPM and each 28AWG wire can carry 2A at 210VDC or 240AC. It has a IP51 water protection rating so will be ok outside.

With this you can mount sensors on a rotating turret, scan the horizon for incoming fighter jets with your home made radar installation.

Dimensions: 22mm Diameter x 26.5mm Length w/ 44.5mm Diameter Flange


Specifications

  • 12 wires, 250mm in length on each side.
  • Voltage: 210VDC / 240VAC
  • Current Rating: 2A
  • Operating Speed: 250RPM
  • Compatible with data bus protocols
  • Transfers analogue and digital signals
